Polywell i2315Ai

Name: i2315Ai
Availability: InStock

Intel® Core™ Ultra Series 2 processor , NVIDIA® RTX4060 Graphics,1 HDMI+2 DP, 3 M.2 slots+WiFi/BT, 5 USB 3.0+Type-C

Featured Highlights

• Intel® Core™ Ultra Series 2 processor
• NVIDIA® RTX4060(2 DP 1.4+1 HDMI 2.1), Type-C
• 2 DDR5 SO-DIMM for up to 128GB Memory
• 3 M.2 NVMe, (one SSD supports M.2 SATA)
• 2 Gigabit LAN, M.2-WiFi/BT
• 5 USB 3.0, Type-C
• 7.1 ALC892 Audio Sound
• DC19V/15.79A Power Adapter (UL/CE/FCC Certified)
• OS Support: Windows 11, Linux, etc.
• Applications: GPU Computing, AI Edge, Video processing, High-Performance PC, Digital Signage, Gaming PC, etc.

Technical specifications
Request more information
Request for price quote
Request for Test Drive

CPU options

• Intel® Core™ Ultra Processors (Series 2)
• Intel® Core™ Ultra 9 Processor 285H
• Intel® Core™ Ultra 7 Processor 255H
• Opiton:Intel® Core™ Ultra processors (Series 1)

Chipset

Memory

• 2 x DDR5 SO-DIMM
• 4800MHz unbuffered non-ECC (Dual Channel I/O)
• Supports up to 128GB

Graphics

• NVIDIA® GeForce RTX4060-8G(2 DP1.4+1 HDMI2.1)Graphics
• Multi-display for up to Quad 4K monitors
• 1 x HDMI® 2.1 ports, supports 4K 60Hz,
• 2 x DP 1.4 ports, supports 8K 60Hz
• 1 x Type-C port (HDMI® 2.1 or DP 1.4 signal for 8K video)

Network

• 2 x Realtek® RTL8111DL Gigabit (10/100/1000 Mb/s) LAN
• 802.11ac/n/g WiFi with Bluetooth 4.0/4.2
• Wake on LAN, PXE boot (Diskless) supported
• Option: additional Gigabit LAN can be added by USB LAN module

Expansion slots

• 2 x M.2 2280 (for PCIe x4 NVMe SSD)
• 1 x M.2 2280 (for SATA-6Gb/s or PCIe NVMe SSD)
• 1 x M.2 2230 (for WiFi+BT or Other Module)

Storage

• 2 x M.2 2280 (for PCIe x4 NVMe SSD)
• 1 x M.2 2280 (for SATA-6Gb/s or PCIe NVMe SSD)

Audio

• Realtek® ALC892 (7.1)
• 2 x 3.5mm Analog Stereo Audio jacks

Back panel I/O

• 2 x USB 3.0 ports
• 1 x HDMI® 2.1 ports
• 2 x DP 1.4 ports
• 2 x LAN port
• 1 x DC Power Connector

Internal I/O

Other I/O

Front panel I/O

• 3 x USB 3.0 ports (Front)
• 1 x Type-C port (Front)
• 2 x 3.5mm Audio jack

Function

System BIOS

• AMI® BIOS
• Watchdog supported

Chassis

• Dimensions: 12.6"(W) x 9.4"(D) x 2.2"(H), Weight: 5.5 lb. (Net) 10 lb. (gross with packaging)
• Cooling: Slim CPU and GPU Fans with Heatsinks
• Color: Grey as default color, option: Black, Silver, Gold. Other custom color available

Power supply

• Power: DC19V 12.5A 240W Power Adapter (UL/CE/FCC Certified)
• Power Cord: Standard US Power Cord included, European Power Cord available as option
• Energy Star Compliance, Idle mode at <1W

OS support

• Windows 11, Linux

Application

• GPU Computing, AI Edge, Video processing, High Performance PC, Digital Signage, Gaming PC, etc.

Environment

• Operating Temperature: 0 to +70 C
• Non operating temperature: -20 to +80 C
• Vibration - Operating: 9.8 m/s2(1.0G) 5 to 500Hz
• Vibration - Non operating: 49 m/s2(5.0G) 15 to 500Hz
• Shock - Operating: 3,920 m/s2 (400G) 2ms
• Shock - Non-Operating: 8,820 m/s2 (900G) 1ms
• Operating Relative Humidity: 10% to 90% (non-condensing)
• Non-operating Relative Humidity: 5% to 95% (non-condensing)
• MTBF: 100,000 Hours
• FCC, CE, RoHS Certified
